Fiber Optic Power Meter with Cover Plate OPM-205:
Fiber Optic Power Meter OPM-205 is mainly used for measuring to continue optical signal capacity and fibre-optical route closed-open testing. It applies single chip microprocessor to carry out control, and with completed function. It was widely used on optical cable construction and maintenance, fibre-optical communication, optical cable sensing, light CAT etc. areas. Machine body pattern design conforms to human body engineering requirements, and it applies advanced cold molding technology, it is beautiful and durable. Light power meter applies built-in detector and laser, and it could make it protected very well. Light power meter has delicate appearance, auto power off , three kinds of backlight mode,wavelength memory function,fibre-optical work identification, manual calibration, wide testing range.
Product characteristic
1、Support lighting
2、Supporting auto power off
3、Supports 7 wavelengths
4、Supporting memory wavelength function
5、Supporting customer self-alignment
6、Supporting SC, FC interface, ST interface
7、Supporting charger baby/computer power supply (apolegamy)
8、Supporting linear(mW) and nonlinearity index（dB） displayed at the same time
Technical Specifications:
|
Wavelength range |
800～1700 |
|
Type of Detector |
InGaAs |
|
Power measurement range |
-70~+3 or -50~+20 |
|
Uncertainty |
±5% |
|
Standard wavelength （nm） |
850、980、1300、1310、1490、1550、1625 |
|
Display resolution |
Linear indication：0.1% Logarithmic indication：0.01dBm |
|
Illumination brightness |
5000mcd |
|
Input voltage (V) |
3~6 |
|
working temperature (℃) |
-10～+60 |
|
Storage temperature (℃) |
-25～+70 |
|
Auto off time (min) |
10 |
|
Battery Working Time (h) |
≥48 |
|
Instrument size (mm) |
131*40*19 |
|
Power Supply |
2 Section 7 battery, rechargeable lithium battery ( apolegamy ) and external input |
|
weight (g) |
53 |
