This 400x Fiber Optical Inspection Microscope is used for inspecting fiber terminations, providing the most critical view of fiber end faces. This mini version is smaller and easier to carry. It produces excellent details of scratches and contamination with its good optical performance and integrated laser safety filters. It is the clear choice for critical examination of polish quality.
The built-in LED light produces lighting into an optical path which enables an optimal view and lighting for your examinations and inspections at any time.
The pre-installed 2.5 mm universal adapter is compatible with SC, FC, ST and E2000. Now the new version comes with a FREE 1.25 mm adapter which is compatible with LC and MU.
Features:
400x Optical Magnification
LED illumination
Laser filter installed for eye protection
Versatile adapter interface
Clear bright images
Smooth focus control
Momentary or push button on / off switch for light source
FREE 1.25 mm and 2.5 mm universal adapters compatible with LC, MU,SC,FC,ST and E2000.
Specifications:
|
Instrument Model |
OFT-400XM |
|
Size |
225mm (8.76″) L x 32mm (1.25″)Diameter |
|
Power Supply |
3pcs AAA alkaline battery |
|
LED Rated Life(h) |
100000 |
|
Weight |
0.6kg |
|
Optical Zoom |
400 times |
|
Control |
Instant switching, precise focusing control |
|
Security Filter |
Built-in IR filter |
|
Adaptor |
1.25 mm universal adapter & 2.5 mm universal adapter |
